| General Parameters: |
|---|
| Status: | Active |
|---|
| Frequency Range (GHz): | 26.5 to 40 |
|---|
| Frequency Min (GHz): | 26.5 |
|---|
| Frequency Max (GHz): | 40 |
|---|
| Insertion Loss (dB): | 4 dB Max |
|---|
| Input/Output VSWR: | 2.0:1 |
|---|
| Peak Power: | 20 Watts (43 dBm) |
|---|
| Input Power: | 20 W |
|---|
| RF Leakage (dBm): | +14 Typ |
|---|
| Recovery Time: | 250 ns Max |
|---|
| Pulse width: | 440 to 670 ns |
|---|
| PRF: | 600 to 900 KHz |
|---|
| Duty Cycle: | 0.4 |
|---|
| Connectors In/Out: | 2.92mm Female/Male Removable |
|---|
| Size: | 0.50" x 0.50" x .22" |
|---|
| Weight: | 1.5 oz Typ |
|---|
| Export Classification (ECCN): | EAR99 |
|---|
| Environmental Ratings: |
|---|
| Operating Temperature: | -40 ºC to +60 ºC |
|---|
| Non-Operating Temperature: | -50 ºC to +70 ºC |
|---|
| Humidity: | MIL-STD-202F, Method 103B Cond. B |
|---|
| Vibration: | MIL-STD-202F, Method 204D Cond. B |
|---|
| Shock: | MIL-STD-202F, Method 213B Cond. B |
|---|
| Altitude: | MIL-STD-202F, Method 105C Cond. B |
|---|
| Temperature Cycle: | MIL-STD-202F, Method 107D Cond. A |
|---|
