PE2-30-6R018R0-3R5-22-12-SFF Active

Low Noise Amplifier

Product Feature

Quantic PMI Model PE2-16-2R06R0-1R8-12-12-SFF is a low noise amplifier that operates over the frequency range of 6 to 18 GHz designed for military and industrial applications that offers a gain of 30 dB and a gain flatness of ±1.5 dB with a noise figure of 5 dB.  The unit is supplied in a standard PE2 housing that can be used as a SMA connectorized or a surface mount component.

Product Specifications

General Parameters:
Status: Active
Frequency Range (GHz): 6 to 18
Frequency Min (GHz): 6
Frequency Max (GHz): 18
Gain (dB): 30 dB Typ
Gain Flatness: ±1.5 dB Max
Noise Figure (dB): 5 dB Max
OP1dB (dBm): 18.5 dBm Min
VSWR In/Out: 2.0:1 Max
DC Voltage (VDC): +12 to +15 VDC
DC Current (mA): 325 mA Max
Connectors: SMA Female - removable
Size: 1.08" x 0.7" x 0.29"
Housing: PE2
Finish: Gold Plated
Environmental Ratings:
Temperature (Operating): -55 °C to +85 °C
Temperature (Storage): -55 °C to +125 °C
