| General Parameters: |
|---|
| Status: | Active |
|---|
| Frequency Range (GHz): | 26.0 to 40 |
|---|
| Frequency Min (GHz): | 26 |
|---|
| Frequency Max (GHz): | 40 |
|---|
| Input Power Max: | 0.5 W CW |
|---|
| VSWR: | 2.0:1 Max |
|---|
| Insertion Loss (dB): | 4.5 dB Typ, 4.75 dB Max (@ 40 GHz) |
|---|
| Slope: | 0.5 ± 0.1 dB/GHz |
|---|
| Amplitude Accuracy: | ±0.5 dB (Compared to best fit straight line) |
|---|
| Connectors In / Out: | 2.92mm Female |
|---|
| Size: | 1.10" x 0.67" x 0.22" |
|---|
| Finish: | Blue Epoxy Polimide Coating IAW MIL-C-22750, TYPE I over Epoxy Polimide Primer IAW MIL-P-23377, TYPE I, CLASS 1 or 3. |
|---|
| Export Classification (ECCN): | EAR99 |
|---|
| Environmental Ratings: |
|---|
| Temperature (Operating): | -40 °C to +85 °C |
|---|
| Temperature (Storage): | -65 °C to +125 °C |
|---|
| Humidity: | MIL-STD-202F, METHOD 103B COND. B |
|---|
| Shock: | MIL-STD-202F, METHOD 213B COND. B |
|---|
| Vibration: | MIL-STD-202F, METHOD 204D COND. B |
|---|
| Altitude: | MIL-STD-202F, METHOD 105C COND. B |
|---|
| Temperature Cycle: | MIL-STD-202F, METHOD 107 |
|---|
