PLO-14R4-CD-1 Preliminary

Phase Locked Resonator Oscillator

PLO-14R4-CD-1
Product Feature
Additional Documents

Quantic PMI Model PLO-14R4-CD-1 is a Phase Locked Resonator Oscillator with an output frequency of 14.4 GHz and an output power of 15 dBm. Package size is 2.25" x 2,25" x 0.63" and is outfitted with SMA female connectors.

Product Specifications

General Parameters:
Status: Preliminary
Output Frequency - fo (GHz): 14.4
Frequency Stability: Same as Reference
Load VSWR: 1.5:1
Output Power (dBm): 15 dBm
Spurious: -80 dBc
Phase Noise: See Product Feature
Harmonics: -20 dBc
External Reference: 50 to 300 MHz
Output Impedance: 50 Ohm
Alarm: TTL High In Lock
DC Current: 280 mA
Power Variation: ±2 dBm
Input Power Level: 0 ± 3 dBm
Supply Voltage: +12 to +15 VDC
Connectors: SMA Female
Size: 2.25" x 2.25" x 0.62"
Export Classification (ECCN): EAR99
Environmental Ratings:
Operating Temperature: -40 °C to +80 °C
Non-Operating Temperature: -65 °C to +125 °C
Vibration: MIL-STD-202, Method 204D Cond. B
Shock: MIL-STD-202, Method 213B Cond. B
Humidity: MIL-STD-202, Method 103B Cond. B
Altitude: MIL-STD-202, Method 105C Cond. B
Temperature Cycle: MIL-STD-202, Method 107D Cond. A
