High Power Limiter

Buy Now

PMI Model No. LM-2G4G-15-100W-SFF is a high power limiter operating in the frequency range 2.0 to 4.0 GHz (Usable 1.0 to 5.0 GHz), with 100 W CW of power handling (+50 dBm) and peak power of 250 W (+54 dBm). This compact housing is fitted with SMA female connectors.

Product Specifications

General Parameters:
Status: Active
Frequency: 2.0 to 4.0 GHz (Usable 1.0 to 5.0 GHz)
Frequency Min: 2.0 GHz
Frequency Max: 4.0 GHz
Insertion Loss: 1.5 dB Max
Input/Output VSWR: 2:1 Max
Power Handling: +50 dBm CW Max (100 W)
+54 dBm Peak, 1 ms Pulse, 10% Duty Cycle (250 W)
Input Power: 4 W CW Min @ 85°C.
1000 W Peak Min @ 85°C
(1 µs Pulse Width, 0.1% Duty Cycle)
Flat Leakage Power: +21 dBm Typ
Recovery Time: 1 µs Max
Connectors In/Out: SMA (F)
Size: 1.00" x 0.68" x 0.35"
Finish: Painted Blue
Environmental Ratings:
Operating Temperature: -40 °C to +85 °C
Non-Operating Temperature: -55 °C to +125 °C
Humidity: MIL-STD-202, Method 103B Cond. B
Vibration: MIL-STD-202, Method 204D Cond. B
Shock: MIL-STD-202, Method 213B Cond. B
Altitude: MIL-STD-202, Method 105C Cond. B
Temperature Cycle: MIL-STD-202, Method 107D Cond. A
