LM-2G18G-10-100W-SFF
Preliminary
Limiter
Quantic PMI Model LM-2G18G-10-100W-SFF is an RF limiter that operates over the 2.0 to 18.0 frequency range.
Product Specifications
| General Parameters: |
|---|
| Status: | Preliminary |
|---|
| Frequency Range (GHz): | 2 to 18 |
|---|
| Frequency Min (GHz): | 2 |
|---|
| Frequency Max (GHz): | 18 |
|---|
| Insertion Loss (dB): | 4 dB |
|---|
| Input/Output VSWR: | 2.0:1 |
|---|
| Power Handling: | 1 Watt CW Max. |
|---|
| Peak Power: | 100 Watts |
|---|
| Input Power: | 1 Watt CW Max. |
|---|
| Leakage Level: | -10 to -5 dBm Typ. |
|---|
| P1dB Limiting Threshold (dBm): | -10 Typ |
|---|
| DC Supply: | +5VDC |
|---|
| Export Classification (ECCN): | EAR99 |
|---|
| Environmental Ratings: |
|---|
| Operating Temperature: | -55 °C to +85 °C |
|---|
| Non-Operating Temperature: | -65 °C to +125 °C |
|---|
| Humidity: | MIL-STD-202, Method 103B Cond. B |
|---|
| Vibration: | MIL-STD-202, Method 204D Cond. B |
|---|
| Shock: | MIL-STD-202, Method 213B Cond. B |
|---|
| Altitude: | MIL-STD-202, Method 105C Cond. B |
|---|
| Temperature Cycle: | MIL-STD-202, Method 107D Cond. A |
|---|
