| General Parameters: |
|---|
| Status: | Active |
|---|
| Frequency Min: | DC |
|---|
| Frequency Max: | 40 GHz |
|---|
| Maximum Input Power: | +30 dBm (1W) |
|---|
| VSWR: | 1.6:1 Typ / 1.8:1 Max |
|---|
| Slope (Frequency/Amplitude): | 0.15 ± 0.05 dB/GHz Typ |
|---|
| Amplitude Accuracy: | ±1 dB Typ (Compared to Best Fit Straight Line) |
|---|
| Connectors In / Out: | 2.92mm Female |
|---|
| Size: | 0.53" x 0.70"x 0.26" |
|---|
| Finish: | Gold |
|---|
| Weight: | 10 gms |
|---|
| Environmental Ratings: |
|---|
| Temperature (Operating): | -55 °C to +85 °C |
|---|
| Temperature (Storage): | -65 °C to +125 °C |
|---|
| Humidity: | MIL-STD-202, METHOD 103B COND. B |
|---|
| Shock: | MIL-STD-202, METHOD 213B COND. B |
|---|
| Vibration: | MIL-STD-202, METHOD 204D COND. B |
|---|
| Altitude: | MIL-STD-202, METHOD 105C COND. B |
|---|
| Temperature Cycle: | MIL-STD-202, METHOD 107D COND. A |
|---|
