| General Parameters: |
|---|
| Status: | Active |
|---|
| Center Frequency, Fo: | 5900 MHz |
|---|
| Notch Bandwidth: | 100 MHz @ 3dB |
|---|
| Passband Insertion Loss: | -1.8 dB MAX. |
|---|
| Passband VSWR: | 1.5:1 MAX. |
|---|
| Size: | 2.90" (L) X 0.65" (W) X 0.75" (H) |
|---|
| Connectors In/Out: | SMA FEMALE CONNECTORS |
|---|
| Weight: | 1 OZ. TYP. |
|---|
| REJECTION @ + - 90 MHz FROM TO: | -30 dB |
|---|
| REJECTION FROM 0 TO 300 MHz: | -65 dB |
|---|
| REJECTION FROM 300 TO 1000MHz:: | -65 dB |
|---|
| 3dB BANDWIDTH:: | 100 MHz |
|---|
| FUNGUS:: | MIL-STD-810C, METHOD 508.2 |
|---|
| Environmental Ratings: |
|---|
| Temperature: | -55°C TO +85°C (OPERATING) |
|---|
| Non-Operating: | -65°C TO +125°C (STORAGE) |
|---|
| Humidity: | MIL-STD-202F, METHOD 103B COND. B |
|---|
| Shock: | MIL-STD-202F, METHOD 213B COND. B |
|---|
| Vibration: | MIL-STD-202F, METHOD 204B COND. B |
|---|
| Altitude: | MIL-STD-202F, METHOD 105C COND. B |
|---|
| Temperature Cycle: | MIL-STD-202F, METHOD 107 |
|---|
| Salt Fog: | MIL-STD-202F, METHOD 107D COND. A |
|---|
