| General Parameters: |
|---|
| Status: | Preliminary |
|---|
| Frequency Range (GHz): | 0.5 to 6.0 GHz |
|---|
| Frequency Min (GHz): | 0.5 GHz |
|---|
| Frequency Max (GHz): | 6 GHz |
|---|
| Threshold: | Adjustable |
|---|
| Detected Output Type: | TTL |
|---|
| VSWR: | 3.0:1 typ |
|---|
| Dynamic Range (dBm): | -20dBm to +10dBm |
|---|
| RF Connectors: | Removable SMA(F) |
|---|
| Size: | 0.80 x 0.65 x 0.20 Inches |
|---|
| Finish: | Painted Blue |
|---|
| Power Supply: | ±5V @ 100mA typ |
|---|
| Output Connector: | Removable SMA(F) |
|---|
| Threshold Adjust Connector: | Solder Pin |
|---|
| Threshold Variation: | ±1.0dB max |
|---|
| Threshold Setting Control: | External Voltage 0 to +5V |
|---|
| Propagation Delay: | 10ns typ 3dB above threshold setting (50% RF Input to 50% Logic at -10dBm) |
|---|
| Minimum Pulse Width: | 50ns typ |
|---|
| Output: | TTL "1" Input Power> Threshold Setting, TTL "0" Otherwise |
|---|
| Maximum RF Input: | 100mW CW max |
|---|
| Temperature Stability: | 1.0dB typ 3.0dB Above Threshold Setting |
|---|
| Export Classification (ECCN): | EAR99 |
|---|
| Environmental Ratings: |
|---|
| Operating Temperature: | -55ºC to +95ºC |
|---|
| Non-Operating Temperature: | -65 ºC to +125 ºC |
|---|
| Humidity: | MIL-STD-202F, Method 103B Cond. B |
|---|
| Shock: | MIL-STD-202F, Method 213B Cond. B |
|---|
| Vibration: | MIL-STD-202F, Method 204D Cond. B |
|---|
| Altitude: | MIL-STD-202F, Method 105C Cond. B |
|---|
| Temperature Cycle: | MIL-STD-202F, Method 107D Cond. A |
|---|
