| General Parameters: |
|---|
| Status: | Active |
|---|
| Frequency Range (GHz): | 7 to 9 |
|---|
| Frequency Min (GHz): | 7 |
|---|
| Frequency Max (GHz): | 9 |
|---|
| Gain (dB): | 30 dB Nom |
|---|
| Gain Flatness (dB): | ±1.5 dB Typ |
|---|
| Noise Figure (dB): | 5 dB Max |
|---|
| OP1dB (dBm): | 20 dBm Min |
|---|
| VSWR In/Out: | 2.0:1 Max |
|---|
| AC Voltage Supply: | 120 to 240 VAC, 47-63 Hz, 15 W Max
Supplied with fuse and 6 foot power cord |
|---|
| DC Voltage Supply: | N/A |
|---|
| RF Connectors (In/Out): | SMA Female |
|---|
| Size: | 4.92" x 4.92" x 2.26" |
|---|
| Finish: | Blue power coated |
|---|
| Export Classification (ECCN): | EAR99 |
|---|
| Environmental Ratings: |
|---|
| Temperature (Operating): | -40 °C to +85 °C |
|---|
| Temperature (Non-Operating): | -40 °C to +100 °C |
|---|
| Humidity: | MIL-STD-202F, METHOD 103B COND. B |
|---|
| Shock: | MIL-STD-202F, METHOD 213B COND. B |
|---|
| Vibration: | MIL-STD-202F, METHOD 204D COND. B |
|---|
| Altitude: | MIL-STD-202F, METHOD 105C COND. B |
|---|
| Temperature Cycle: | MIL-STD-202F, METHOD 107D COND. A |
|---|
