| General Parameters: |
|---|
| Status: | Active |
|---|
| Frequency Min: | 1.9 GHz |
|---|
| Frequency Max: | 5.6 GHz |
|---|
| Phase States: | 0° / 180° |
|---|
| Insertion Loss: | 2.5 dB typ., 3.0 dB max. |
|---|
| VSWR: | 2.0:1 |
|---|
| Control Type: | TTL |
|---|
| Speed: | 75 ns max On/Off |
|---|
| Input Power: | +20 dBm Operating |
|---|
| Input Power (Survival): | 0.5 Watt CW, 1us Pulse Width Survival |
|---|
| Carrier Suppression: | 20 dB Typ |
|---|
| Power Supply: | +5 VDC @ 75 mA max, -5 VDC @ 20 mA max |
|---|
| Size: | 1.0" X 1.0" X 0.5" |
|---|
| Weight: | < 2 Ounces |
|---|
| Environmental Ratings: |
|---|
| Temperature (Operating): | -55 ºC to +85 ºC |
|---|
| Temperature (Storage): | -65 ºC to +125 ºC |
|---|
| Humidity: | MIL-STD-202F, Method 103B Cond. B |
|---|
| Shock: | MIL-STD-202F, Method 213B Cond. B |
|---|
| Vibration: | MIL-STD-202F, Method 204D Cond. B |
|---|
| Altitude: | MIL-STD-202F, Method 105C Cond. B |
|---|
| Temperature Cycle: | MIL-STD-202F, Method 107D Cond. A |
|---|
