| General Parameters: |
|---|
| Status: | Active |
|---|
| Frequency Min: | 1 GHz |
|---|
| Frequency Max: | 2 GHz |
|---|
| Phase States: | 0° / 180° |
|---|
| Insertion Loss: | 3.0 dB Typ, 6.0 dB Max |
|---|
| VSWR: | 2.0:1 |
|---|
| Control Type: | TTL |
|---|
| Amplitude Balance: | 1 dB Typical, 1.3 dB Maximum |
|---|
| Switching Time: | 1 us |
|---|
| Input Power: | +20 dBm Operating |
|---|
| Input Power (Survival): | 0.5 Watt, 1 us Pulse Width |
|---|
| Carrier Suppression: | +20 dBc |
|---|
| Control: | TTL |
|---|
| Power Supply: | +V: +5V @ 75 mA Maximum, - V: - 5V @ 20 mA Maximum |
|---|
| Size: | 1.00" x 1.00" x 0.50" |
|---|
| Weight: | 2.0 oz. |
|---|
| Environmental Ratings: |
|---|
| Temperature (Operating): | -55ºC to +85 ºC Operating |
|---|
| Temperature (Storage): | -65 ºC to +125 ºC |
|---|
| Humidity: | MIL-STD-202F, Method 103B Cond. B |
|---|
| Shock: | MIL-STD-202F, Method 213B Cond. B |
|---|
| Vibration: | MIL-STD-202F, Method 204D Cond. B |
|---|
| Altitude: | MIL-STD-202F, Method 105C Cond. B |
|---|
| Temperature Cycle: | MIL-STD-202F, Method 107D Cond. A |
|---|
