| General Parameters: |
|---|
| Status: | Active |
|---|
| Frequency Range (GHz): | 14.5 to 15.5 |
|---|
| Frequency Min (GHz): | 14.5 |
|---|
| Frequency Max (GHz): | 15.5 |
|---|
| Phase Balance: | ±10° Max |
|---|
| Insertion Loss (dB): | 2.6 dB Max
(6.02 dB Nominal Split) |
|---|
| Isolation (dB): | 18 dB Min |
|---|
| Amplitude Balance: | ±0.8 dB Max @ 25°C
±1.0 dB Max @ -40°C to +85°C |
|---|
| VSWR: | 1.60:1 Max |
|---|
| Impedance: | 50 Ohm |
|---|
| Power Handling: | Average: 30 W Max
Peak: 1 KW Max |
|---|
| Connectors: | SMA Female |
|---|
| Finish: | Painted Blue |
|---|
| Size: | 3.12" x 3.12" x 0.43" |
|---|
| Export Classification (ECCN): | EAR99 |
|---|
| Environmental Ratings: |
|---|
| Temperature: | -40 °C to +85 °C |
|---|
| Humidity: | Up to 95%, Non-Condensing |
|---|
| Shock: | MIL-STD-202, Method 213B Cond. B |
|---|
| Vibration: | MIL-STD-202, Method 204D Cond. B |
|---|
| Altitude: | MIL-STD-202, Method 105C Cond. B |
|---|
| Temperature Cycle: | MIL-STD-202, Method 107D Cond. A |
|---|
