| General Parameters: |
|---|
| Status: | Active |
|---|
| Frequency Range (GHz): | 1 to 2 |
|---|
| Frequency Min (GHz): | 1 |
|---|
| Frequency Max (GHz): | 2 |
|---|
| Gain (dB): | 9 dB Min |
|---|
| Gain Flatness: | ±1.0 dB Max |
|---|
| Noise Figure (dB): | 4.5 dB Max up to +25°C,
5 dB Max @ +85°C |
|---|
| VSWR In/Out: | 2.0:1 Max |
|---|
| DC Voltage (VDC): | +6 V Fixed, No Internal Voltage Regulation or Reverse Protection |
|---|
| DC Current (mA): | 200 mA Max |
|---|
| Input Power: | 2 W CW (60 dBm Peak 0.1% DC, 1 µs PW Max) |
|---|
| P1dB Compression Point: | +12 dBm Min @ -1 V Limiter Bias |
|---|
| Connectors: | SMA Male (IN) - Female (OUT) |
|---|
| Size: | PE2 |
|---|
| Finish: | Gold Plated |
|---|
| Export Classification (ECCN): | EAR99 |
|---|
| Environmental Ratings: |
|---|
| Temperature: | -55 °C to +85 °C (Operating)
-55 °C to +125 °C (Storage) |
|---|
| Humidity: | MIL-STD-202F, METHOD 103B COND B. |
|---|
| Shock: | MIL-STD-202F, METHOD 213B COND B. |
|---|
| Altitude: | MIL-STD-202F, METHOD 105C COND B. |
|---|
