PLDRO-18D75G-25M-EXT-ROHS Active

Phase Locked Oscillator (PLDRO)

Quantic PMI Model No. PLDRO-17D45G-25M-EXT-ROHS is a PLDRO with an output frequency of 17.45 GHz. It has a reference frequency of 25 MHz, an output power of 13.8 dBm, a no lock VSWR of 3:1, an output spurious of -75 dBc, an output harmonic of -25 dBc, a sub harmonic of -60 dBc, a reference input power of 10 to -3 dBm, and a reference input spurious of -80 dBc. This model has SMA female connectors and measures 2.25" x 2.25" x 1.41".

Product Specifications

General Parameters:
Status: Active
Output Frequency (fo): 18.750 GHz
Output Power: +13 to +15 dBm
Spurious: -75 dBc Max
Harmonics: -25 dBc Max
Sub Harmonics: -60 dBc Max (0.5 Fo, 1.5 Fo, 2.5 Fo, etc.)
DC Power: +12 +/- 0.5 VDC, 500 mA Max
RF Connector: SMA Female
Reference Input Power: +10 ± 3 dBc
Reference Frequency: 25 MHz (External)
VSWR: 3.0:1 Min
Lock Indicator: TTL High for In-Lock
Environmental Ratings:
Operating Temperature: -40 °C to 75 °C
