PLDRO-13D675-25M-EXT-ROHS
Preliminary
PMI model PLDRO-13D675-25M-EXT-ROHS is a PLDRO with an output frequency of 13.675 GHz. This model is outfitted with SMA connectors.
Product Specifications
General Parameters: |
Status: | Preliminary |
Output Frequency (fo): | 13.675 GHz |
Output Power: | +13 to +15 dBm |
Spurious: | -80 dBc max. |
Harmonics: | -20 dBc Max (Output) |
DC Power: | +12 +/- 0.5 VDC, 450 mA Max |
Reference Input Power: | +7 ± 3 dBc |
Connectors: | SMA Female |
Reference Frequency: | 25 MHz (External) |
VSWR: | 3.0:1 Min |
Input Frequency: | 25 MHz, ONLY AVAILABLE FREQUENCY |
Lock Indicator: | TTL HIGH FOR IN-LOCK TTL LOW FOR OUT-OF-LOCK |
Environmental Ratings: |
Operating Temperature: | -40° to 75°C |
