| General Parameters: |
|---|
| Status: | Preliminary |
|---|
| Frequency Range: | 0.2 to 0.4 GHz |
|---|
| Frequency Min: | 0.2 GHz |
|---|
| Frequency Max: | 0.4 GHz |
|---|
| Gain: | 16 dB typ. |
|---|
| Gain Flatness: | ±0.5 dB max. |
|---|
| Noise Figure: | 3.5 dB typ. |
|---|
| VSWR In/Out: | 2.2:1 max. |
|---|
| DC Voltage Supply: | +12 to +15 |
|---|
| DC Current Draw: | 150mA max. |
|---|
| OP1dB: | 14dBm min. |
|---|
| Environmental Ratings: |
|---|
| Temperature: | -40ºC to +85 ºC Operating |
|---|
| Non-Operating: | -40ºC to +100 ºC Non-Operating |
|---|
| Humidity: | MIL-STD-202F, Method 103B Cond. B |
|---|
| Shock: | MIL-STD-202F, Method 213B Cond. B |
|---|
| Vibration: | MIL-STD-202F, Method 204D Cond. B |
|---|
| Altitude: | MIL-STD-202F, Method 105C Cond. B |
|---|
| Temperature Cycle: | MIL-STD-202F, Method 107D Cond. A |
|---|
