| General Parameters: |
|---|
| Status: | Active |
|---|
| Output Frequency - fo (GHz): | 29.8 |
|---|
| Frequency Stability: | Same as reference |
|---|
| Load VSWR: | 1.5:1 |
|---|
| Output Power (dBm): | 13 dBm Min |
|---|
| Spurious: | -60 dBc Max |
|---|
| Phase Noise: | -65 dBc/Hz @ 100 Hz Max
-81 dBc/Hz @ 1 kHz Max
-95 dBc/Hz @ 10 kHz Max
-107 dBc/Hz @ 100 kHz Max
-123 dBc/Hz @ 1 MHz Max |
|---|
| Harmonics: | -20 dBc Max |
|---|
| Reference Frequency: | 100 MHz (Sinewave) - External |
|---|
| Lock Detector: | TTL High - Lock |
|---|
| Input Level: | +3 to 13 dBm |
|---|
| DC Current: | 300 mA Max |
|---|
| Reference Phase Noise: | -135 dBc/Hz @ 100 Hz Max
-155 dBc/Hz @ 1 kHz Max
-165 dBc/Hz @ 10 kHz Max
-165 dBc/Hz @ 100 kHz Max |
|---|
| Supply Voltage: | +12 to +15 VDC |
|---|
| Connectors: | RF OUT: 2.92mm Female
REF: SMA Female
Power: Through Cap |
|---|
| Size: | 2.25" x 2.25" x 0.62" |
|---|
| Export Classification (ECCN): | EAR99 |
|---|
| Environmental Ratings: |
|---|
| Operating Temperature: | -20 °C to +85 °C |
|---|
| Non-Operating Temperature: | -55 °C to +125°C |
|---|
| Vibration: | MIL-STD-202, METHOD 204D COND. B |
|---|
| Shock: | MIL-STD-202, METHOD 213B COND. B |
|---|
| Humidity: | MIL-STD-202, METHOD 103B COND. B |
|---|
| Altitude: | MIL-STD-202, METHOD 105C COND. B |
|---|
| Temperature Cycle: | MIL-STD-202, METHOD 107D COND. A |
|---|
