PMI Model No. LM-910D5-100W-1KWP-SFM is an RF limiter that operates in the frequency range of 9.0 to 10.5 GHz. This limiter can handle 100 W CW for all temperatures (-55°C to +85°C) and 1 kW peak (1% duty cycle, 1 usec maximum pulse width) energy input, and provides maximum leakage of +17 dBm. This model has a low insertion loss of 2.0 dB and a typical recovery time of 100 ns.
