| General Parameters: |
|---|
| Status: | Active |
|---|
| Frequency Range (GHz): | 0.3 to 1 |
|---|
| Frequency Min (GHz): | 0.3 |
|---|
| Frequency Max (GHz): | 1 |
|---|
| Input/Output VSWR: | 2:1 dB Max |
|---|
| Power Handling: | +54 dBm CW Max (250 W)
Peak Power 360 W, Pulse 2 ms, 10% Duty Cycle |
|---|
| Input Power: | +54 dBm CW Max (250 W)
Peak Power 360 W, Pulse 2 ms, 10% Duty Cycle |
|---|
| Flat Leakage Power: | +21 dBm Typ |
|---|
| RF Leakage (dBm): | +21 Typ |
|---|
| Recovery Time: | 1 µs Max |
|---|
| Connectors In/Out: | SMA (F) |
|---|
| Size: | 1.00" x 0.68" x 035" |
|---|
| Finish: | Painted Blue |
|---|
| Export Classification (ECCN): | EAR99 |
|---|
| Environmental Ratings: |
|---|
| Operating Temperature: | -40 °C to +85 °C |
|---|
| Non-Operating Temperature: | -55 °C to +125 °C |
|---|
| Humidity: | MIL-STD-202, Method 103B Cond. B |
|---|
| Vibration: | MIL-STD-202, Method 204D Cond. B |
|---|
| Shock: | MIL-STD-202, Method 213B Cond. B |
|---|
| Altitude: | MIL-STD-202, Method 105C Cond. B |
|---|
| Temperature Cycle: | MIL-STD-202, Method 107D Cond. A |
|---|
