| General Parameters: |
|---|
| Status: | Active |
|---|
| Frequency Range (GHz): | 2 to 8 |
|---|
| Frequency Min (GHz): | 2 |
|---|
| Frequency Max (GHz): | 8 |
|---|
| Insertion Loss (dB): | 1.0 Typ
1.2 Max |
|---|
| Input/Output VSWR: | 2.0:1 Max |
|---|
| Peak Power: | 1 kW Max |
|---|
| Input Power: | 3 W Max |
|---|
| Leakage Power: | 80 mW Typ |
|---|
| RF Leakage (dBm): | 19 Typ |
|---|
| Recovery Time: | 1000 ns Typ |
|---|
| Connectors In/Out: | 2.92mm (M) / (F) |
|---|
| Size: | 1.31" (Length)
0.38" (Diameter) |
|---|
| Weight: | <1 oz |
|---|
| Export Classification (ECCN): | EAR99 |
|---|
| Environmental Ratings: |
|---|
| Operating Temperature: | -55 °C to +125 °C
Derate Power Handling to Zero @ +125 °C |
|---|
| Non-Operating Temperature: | -65 °C to +125 °C |
|---|
| Humidity: | MIL-STD-202F, Method 103B Cond. B |
|---|
| Vibration: | MIL-STD-202F, Method 204B Cond. B |
|---|
| Shock: | MIL-STD-202F, Method 213B Cond. B |
|---|
| Altitude: | MIL-STD-202F, Method 105C Cond. B |
|---|
| Temperature Cycle: | MIL-STD-202F, Method 107D Cond. A |
|---|
