| General Parameters: |
|---|
| Status: | Preliminary |
|---|
| Frequency Range (GHz): | 11 to 14 |
|---|
| Frequency Min (GHz): | 11 |
|---|
| Frequency Max (GHz): | 14 |
|---|
| Input/Output VSWR: | 2.0:1 |
|---|
| Input Power: | 20 W (43 dBm) |
|---|
| RF Leakage (dBm): | 7 Typ |
|---|
| Pulse width: | 1 ms |
|---|
| Duty Cycle: | 20% |
|---|
| Connectors In/Out: | SMA (M/F) |
|---|
| Size: | 0.75" x 1.00" X 0.30" |
|---|
| Weight: | 1.5 oz. Typ |
|---|
| Export Classification (ECCN): | EAR99 |
|---|
| Environmental Ratings: |
|---|
| Operating Temperature: | -40 ºC to +85 ºC |
|---|
| Non-Operating Temperature: | -65 ºC to +125 ºC |
|---|
| Humidity: | MIL-STD-202F, Method 103B Cond. B |
|---|
| Vibration: | MIL-STD-202F, Method 204D Cond. B |
|---|
| Shock: | MIL-STD-202F, Method 213B Cond. C |
|---|
| Thermal Shock: | MIL-STD-202F, Method 107D Cond. A |
|---|
| Fungus: | MIL-STD-810F, Method 508.5 |
|---|
| Salt Spray: | MIL-STD-202F, Method 101D+EST Cond. B |
|---|
