| General Parameters: |
|---|
| Status: | Active |
|---|
| Frequency: | 0.01 to 17.0 GHz |
|---|
| Frequency Min: | 0.01 GHz |
|---|
| Frequency Max: | 17.0 GHz |
|---|
| Insertion Loss: | 2.3 dB Max |
|---|
| Input/Output VSWR: | 2:1 Max |
|---|
| Power Handling: | +40 dBm CW Max
Peak Power 100 W, Pulse 1 µs 1% Duty Cycle |
|---|
| Input Power: | +40 dBm CW Max
Peak Power 100 W, Pulse 1 µs 1% Duty Cycle |
|---|
| Flat Leakage Power: | +20 dBm Typ |
|---|
| Recovery Time: | 1 µs Max |
|---|
| Connectors In/Out: | SMA (F) |
|---|
| Size: | 1.00" x 0.68" x 0.35" |
|---|
| Finish: | Painted Blue |
|---|
| Environmental Ratings: |
|---|
| Operating Temperature: | -40 °C to +85 °C |
|---|
| Non-Operating Temperature: | -55 °C to +125 °C |
|---|
| Humidity: | MIL-STD-202, Method 103B Cond. B |
|---|
| Vibration: | MIL-STD-202, Method 204D Cond. B |
|---|
| Shock: | MIL-STD-202, Method 213B Cond. B |
|---|
| Altitude: | MIL-STD-202, Method 105C Cond. B |
|---|
| Temperature Cycle: | MIL-STD-202, Method 107D Cond. A |
|---|
