LM-0R4G5G5G-20W-SFF-OPT400M500M Preliminary

PMI Model No. LM-0R4G5G5G-20W-SFF-OPT400M500M is an RF Limiter that operates in the 400 to 500MHz frequency range. This limiter can handle 20W CW input power and provides a typical leakage of +13dBm. This model has a low insertion loss of 1.0dB typical and a recovery time of 10nsec typical

Product Specifications

General Parameters:
Status: Preliminary
Frequency Range (GHz): 0.4 to 0.5 GHz
Frequency Min (GHz): 0.4
Frequency Max (GHz): 0.5
Insertion Loss (dB): 1.0 typ
Input/Output VSWR: 2.0:1 max
Input Power: 20 Watts CW max, 200W Peak, 10% Duty Cycle, 1uS PW
RF Leakage (dBm): 13 typ
Recovery Time: 10 ns typ
Impedance: 50 Ohms
Connectors In/Out: SMA(F)
Finish: Painted Blue
Environmental Ratings:
Operating Temperature: -40ºC to +70ºC
Non-Operating Temperature: -65 ºC to +125 ºC
Humidity: MIL-STD-202F, Method 103B Cond. B
Vibration: MIL-STD-202F, Method 204B Cond. B
Shock: MIL-STD-202F, Method 213B Cond. B
Altitude: MIL-STD-202F, Method 105C Cond. B
Temperature Cycle: MIL-STD-202F, Method 107D Cond. A
