| General Parameters: |
|---|
| Status: | Preliminary |
|---|
| Frequency Range: | 6.0 to 18.0 GHz |
|---|
| Frequency Min: | 6.0 GHz |
|---|
| Frequency Max: | 18 GHz |
|---|
| Insertion Loss: | 1.5 dB Max |
|---|
| Isolation: | 10.0 dB Min |
|---|
| VSWR: | 1.9 Max |
|---|
| Forward Power: | 60 Watts |
|---|
| Reverse Power: | 10 Watts |
|---|
| Direction: | SMA Male/SMA Female |
|---|
| Finish: | Painted Blue |
|---|
| Environmental Ratings: |
|---|
| Temperature: | -30 °C TO +70 °C (Operating) |
|---|
| Humidity: | MIL-STD-202, Method 103B Cond. B |
|---|
| Shock: | MIL-STD-202, Method 213B Cond. B |
|---|
| Vibration: | MIL-STD-202, Method 204D Cond B. |
|---|
| Altitude: | MIL-STD-202, Method 105C Cond B. |
|---|
| Temperature Cycle: | MIL-STD-202, Method 107D Cond A. |
|---|
