| General Parameters: |
|---|
| Status: | Preliminary |
|---|
| Frequency Range: | 1.0 to 2.0 GHz |
|---|
| Frequency Min: | 1.0 GHz |
|---|
| Frequency Max: | 2.0 GHz |
|---|
| Insertion Loss: | 0.6 dB Max |
|---|
| Isolation: | 17 dB Min |
|---|
| VSWR: | 1.4:1 Max |
|---|
| Forward Power: | 100 Watts Max |
|---|
| Reverse Power: | 30 Watts Max |
|---|
| Connectors: | SMA Female |
|---|
| Environmental Ratings: |
|---|
| Temperature: | -30°C TO +75°C (OPERATING)
-35°C TO +80°C (STORAGE) |
|---|
| Humidity: | MIL-STD-202, METHOD 103B COND. B |
|---|
| Shock: | MIL-STD-202, METHOD 213B COND. B |
|---|
| Vibration: | MIL-STD-202, METHOD 204D COND. B |
|---|
| Altitude: | MIL-STD-202, METHOD 105C COND. B |
|---|
| Temperature Cycle: | MIL-STD-202, METHOD 107D COND. A |
|---|
