ISO-1826D5-16-SMF Preliminary

Product Feature

PMI Model No. ISO-1826D5-16-SMF is an isolator that operates over the frequency range of 18.0 to 26.5 GHz. It has a maximum insertion loss of 1.6 dB and a minimum isolation of 16 dB. This model is outfitted with a SMA male input connector and a SMA female output connector.

Product Specifications

General Parameters:
Status: Preliminary
Frequency Range: 18.0 to 26.5 GHz
Frequency Min: 18.0 GHz
Frequency Max: 26.5 GHz
Insertion Loss: 1.6 dB max.
Isolation: 16 dB min.
VSWR: 1.6 max.
Forward Power: 10 W
Reverse Power: 2 W
Connectors: SMA (M)/SMA (F)
Finish: Painted Blue
Environmental Ratings:
Temperature: -30°C to +70°C
Humidity: MIL-STD-202, Method 103B Cond. B
Shock: MIL-STD-202, Method 213B Cond. B
Vibration: MIL-STD-202, Method 204D Cond. B
Altitude: MIL-STD-202, Method 105C Cond. B
Temperature Cycle: MIL-STD-202, Method 107D Cond. A
