| General Parameters: |
|---|
| Status: | Active |
|---|
| Frequency Min: | DC |
|---|
| Frequency Max: | 40.0 GHz |
|---|
| Maximum Input Power: | +30 dBm (1W) |
|---|
| VSWR: | 1.6:1 Typ / 1.8:1 Max |
|---|
| Insertion Loss: | 10.0 dB @ 10 MHz to 2.0 GHz Typ
2.0 dB @ 38.0 to 40.0 GHz Typ |
|---|
| Slopes: | 0.25 ± 0.06 dB/GHz Typ |
|---|
| Amplitude Accuracy: | ±1 dB Typ (Compared to Best Fit Straight Line) |
|---|
| Connectors In / Out: | 2.92mm (F) Removable |
|---|
| Size: | 0.53" x 0.56" x 0.18" |
|---|
| Finish: | Gold Plated |
|---|
| Weight: | 10 g Max |
|---|
| Environmental Ratings: |
|---|
| Temperature (Operating): | -55 °C to +85 °C |
|---|
| Temperature (Storage): | -65 °C to +125 °C |
|---|
| Humidity: | MIL-STD-202, Method 103B Cond. B |
|---|
| Shock: | MIL-STD-202, Method 213B Cond. B |
|---|
| Vibration: | MIL-STD-202, Method 204D Cond. B |
|---|
| Altitude: | MIL-STD-202, Method 105C Cond. B |
|---|
| Temperature Cycle: | MIL-STD-202, Method 107D Cond. A |
|---|
