| General Parameters: |
|---|
| Status: | Active |
|---|
| Frequency (GHz): | 9 |
|---|
| Output Frequency, Fo (GHz): | 9 |
|---|
| Output Power (dBm): | 16 dBm Max,
11 dBm Min |
|---|
| Spurious (dBc): | -55 dBc Min |
|---|
| Harmonics (dBc): | -20 dBc Min |
|---|
| Harmonics & Sub-Harmonics (dBc): | -20 dBc Min |
|---|
| Mechanical Tuning Frequency: | ±25 MHz |
|---|
| Frequency Stability: | 9.7 MHz Max |
|---|
| Phase Noise: | -75 dBc / Hz Min (+25 °C @ 10 kHz) |
|---|
| Pushing: | 0.1 MHz / V Max |
|---|
| Pulling: | ±4 MHz Max @ VSWR |
|---|
| DC Supply: | +15 VDC (±5%) @ 150 mA Max |
|---|
| Connectors: | RF: SMA Female
Power: RFI Solder Terminal |
|---|
| Size: | 1.35" x 1.98" x 0.69" |
|---|
| Finish: | Painted Blue |
|---|
| Weight: | 3.7 oz |
|---|
| Export Classification (ECCN): | EAR99 |
|---|
| Environmental Ratings: |
|---|
| Temperature (Operating): | -20 °C to +71 °C |
|---|
| Temperature (Non-Operating): | -62 °C to +85 °C |
|---|
| Humidity: | MIL-STD-202, METHOD 103B COND. B |
|---|
| Shock: | MIL-STD-202, METHOD 213B COND. B |
|---|
| Vibration: | MIL-STD-202, METHOD 204D COND. B |
|---|
| Altitude: | MIL-STD-202, METHOD 107D COND. A |
|---|
