CIR-2G4G-16-SFF Preliminary

PMI Model No. CIR-2G4G-16-SFF is a circulator that operates over the frequency range 2.0 to 4.0 GHz. It has an insertion loss of 0.6 dB and an isolation of 16 dB. It is outfitted with SMA Female connectors.

Product Specifications

General Parameters:
Status: Preliminary
Frequency Range: 2.0 to 4.0 GHz
Frequency Min: 2.0 GHz
Frequency Max: 4.0 GHz
Insertion Loss: 0.6 dB max.
Isolation: 16 dBm min.
VSWR: 1.35:1 max.
Forward Power: 80 W typ.
Direction: 1?2?3
Connectors: SMA (F)
Environmental Ratings:
Temperature: 0ºC to +60 ºC Operating
-5ºC to +65 ºC Non-Operating
Humidity: MIL-STD-202, Method 103B Cond. B
Shock: MIL-STD-202, Method 213B Cond. B
Vibration: MIL-STD-202, Method 204D Cond. B
Altitude: MIL-STD-202, Method 105C Cond. B
Temperature Cycle: MIL-STD-202, Method 107D Cond. A
