| General Parameters: |
|---|
| Status: | Preliminary |
|---|
| Type: | 2-Way |
|---|
| Frequency Min: | 1.0 GHz |
|---|
| Frequency Max: | 4.0 GHz |
|---|
| Isolation: | 20 dB Min |
|---|
| Insertion Loss: | 0.5 dB Max (ABOVE 3.01 dB SPLIT) |
|---|
| VSWR (In/Out): | 1.25:1 Max, 1.20:1 Max |
|---|
| Amplitude Balance: | ±0.2 dB Max |
|---|
| Phase Balance: | ±2° Max |
|---|
| Power Handling: | FORWARD: 30 WATTS Max
REVERSED: 1 WATT Max |
|---|
| Impedance: | 50 OHMs |
|---|
| Connectors: | SMA Female |
|---|
| Finish: | Painted Blue |
|---|
| Environmental Ratings: |
|---|
| Operating Temperature: | -55 °C TO +85 °C |
|---|
| Non-Operating Temperature: | -65 °C TO +125 °C |
|---|
| Humidity: | UP TO 95%, NON-CONDENSING |
|---|
| Shock: | MIL-STD-202, METHOD 213B COND. B |
|---|
| Vibration: | MIL-STD-202, METHOD 204D COND. B |
|---|
| Altitude: | MIL-STD-202, METHOD 105C COND. B |
|---|
| Temperature Cycle: | MIL-STD-202, METHOD 107D COND. A |
|---|
