| General Parameters: |
|---|
| Status: | Preliminary |
|---|
| Type: | 2-Way |
|---|
| Frequency Min: | 18.0 GHz |
|---|
| Frequency Max: | 25.0 GHz |
|---|
| Isolation: | 18 dB min. |
|---|
| Insertion Loss: | 1.2 dB max. (Above 3.01 dB Split) |
|---|
| VSWR (In/Out): | 1.50:1 max. |
|---|
| Amplitude Balance: | ±0.5 dB max. |
|---|
| Phase Balance: | ±5° max. |
|---|
| Power Handling: | Forward: 20 W max.
Reversed: 0.5 W max. |
|---|
| Impedance: | 50 Ohms |
|---|
| Connectors: | SMA (F) |
|---|
| Finish: | Painted Blue |
|---|
| Environmental Ratings: |
|---|
| Operating Temperature: | -55°C to +85°C |
|---|
| Non-Operating Temperature: | -65°C to +125°C |
|---|
| Humidity: | Up to 95%, Non-Condensing (Operating) |
|---|
| Shock: | MIL-STD-202, Method 213B Cond. B |
|---|
| Vibration: | MIL-STD-202, Method 204D Cond. B |
|---|
| Altitude: | MIL-STD-202, Method 105C Cond. B |
|---|
| Temperature Cycle: | MIL-STD-202, Method 107D Cond. A |
|---|
