| General Parameters: |
|---|
| Status: | Active |
|---|
| Center Frequency (GHz): | 1.8 |
|---|
| Bandwidth (GHz): | 0.1 |
|---|
| Insertion Loss (dB): | 1.5 dB |
|---|
| Rejection: | -60 dBc @ 1.64 and 2 GHz |
|---|
| VSWR: | 1.5:1 Max |
|---|
| Connectors: | SMA Female / Female |
|---|
| Size: | 2.7" x 1.2" x 0.5" |
|---|
| Export Classification (ECCN): | EAR99 |
|---|
| Environmental Ratings: |
|---|
| Temperature: | -55 ºC to +85 ºC Operating,
-65 ºC to +125 ºC Non-Operating |
|---|
| Humidity: | MIL-STD-202F, Method 103B Cond. B |
|---|
| Shock: | MIL-STD-202F, Method 213B Cond. B |
|---|
| Vibration: | MIL-STD-202F, Method 204D Cond. B |
|---|
| Altitude: | MIL-STD-202F, Method 105C Cond. B |
|---|
| Temperature Cycle: | MIL-STD-202F, Method 107D Cond. A |
|---|
