| General Parameters: |
|---|
| Status: | Active |
|---|
| Center Frequency (GHz): | 8.25 |
|---|
| Bandwidth (GHz): | 0.5 |
|---|
| Insertion Loss (dB): | 0.8 dB |
|---|
| Power Handling (dBm): | 10 W CW / 100 W peak |
|---|
| Rejection: | -32 dBc @ 7.25 to 7.75 GHz |
|---|
| VSWR: | 2.0:1 Max |
|---|
| Connectors: | SMA Female |
|---|
| Size: | 2.3" x 0.5" x 0.5" |
|---|
| Export Classification (ECCN): | EAR99 |
|---|
| Environmental Ratings: |
|---|
| Temperature: | -40 ºC to +85 ºC Operating,
-40 ºC to +100 ºC Non-Operating |
|---|
| Humidity: | MIL-STD-202F, Method 103B Cond. B |
|---|
| Shock: | MIL-STD-202F, Method 213B Cond. B |
|---|
| Vibration: | MIL-STD-202F, Method 204D Cond. B |
|---|
| Altitude: | MIL-STD-202F, Method 105C Cond. B |
|---|
| Temperature Cycle: | MIL-STD-202F, Method 107D Cond. A |
|---|
