Single Pole - Ten Throw (SP10T)

Part NumberStatusFrequencyFrequency MinFrequency MaxReflective / AbsorptiveIsolationInsertion LossSwitching Speed
P10T-0R3G2G-60-R-SFFPreliminary0.3 to 2.0 GHz0.3 GHz2 GHzReflective60 dB min.3.0 dB max.100 ns max.
P10T-0R5G18G-60-R-SFFPreliminary0.5 to 18.0 GHz0.5 GHz18 GHzReflective60dB min.4.5dB max.100 nsec max.
P10T-9K3G-35-R-SFF-INDPreliminary9kHz to 3.0 GHz0.000009 GHz3 GHzReflective
-
5.5dB typ50% TTL to 10%/90% RF, 1us goal
P10T-0R5G18G-60-T-SFFPreliminary0.5 to 18.0 GHz0.5 GHz18 GHzReflective60dB min.5.0dB max.100 nsec max.
